Thyssen elevator host inverter CPI32 CPI15 CPI26 CPI48 CPI60OS imported from Germany Brief Introduction

1. What CPI32 Really Is

• Power Range: 3 × 380–480 VAC, 2.2–75 kW, 150 % overload for 60 s
• Control: 32-bit DSP, vector torque loop 50 µs, speed loop 500 µs
• Output: 0–400 V, 0–320 Hz, 95 % regeneration efficiency
• Interfaces: CAN-open 125 kbit/s + 0–10 V speed reference, incremental encoder 1,024 ppr
• Protection: IP20 PCB, over-current, over-temp, under-voltage, short-circuit
• Size: 180 × 130 × 55 mm (2.2 kW) — DIN-rail or chassis mount
• Firmware: pre-loaded V3.10; checksum matches Thyssen original 0xC4F9

2. Where It Is Used

• Thyssen SkyRise®, Evolution® 1.0–4.0 m s⁻¹ with PM machines 2.2–75 kW
• Thyssen TCM-MC3 retrofit kits
• Chinese super-MRL controllers with 380–480 V class motors
• Suitable for 1–64 floors, simplex or group (≤8 cars)

3. Commissioning – 20-Minute Plug-and-Play

1. Remove old CPI32 — undo 4 DIN-rail clips; unplug 40-way ribbon, 6-way CAN, 4-way motor.
2. Inspect bus bars — if burnt >1 mm, replace copper (Nanjing Zhuye part CB-BUS-45A).
3. Insert CPI32 — snap until latches click; reconnect all keyed plugs.
4. Connect brake resistor to B+/B-; set jumper J3 to “400 V 4 Ω”.
5. Apply 24 V control — green LED blinks 1 Hz while loading parameters, then steady.
6. Auto-tune: press and hold TUNE for 3 s; inverter rotates 1/8 turn, stores stator resistance.
7. Run full-speed inspection — verify current <110 % rated, regeneration 95 %.

4. Daily Operation – What the Inverter Actually Does

• Updates torque every 50 µs; speed ripple <0.02 % — passengers feel nothing
• Auto-compensates for rope stretch; stores creep data every trip
• Built-in 24 h self-test — if DC bus ripple >5 V, “CPI Ripple Fault” is logged
• Regenerative braking feeds 95 % of braking energy back to mains — saves 15 % power
• Temperature sensor derates current above 70 °C — no summer shutdowns

5. Replacement Cycle & Preventive Maintenance

• High-speed office (>1,000 starts day⁻¹) – blow dust every 3 months, replace inverter every 8 years
• Residential tower (300–600 starts day⁻¹) – inspect annually, replace every 12 years
• Low-rise freight (≤200 starts day⁻¹) – inspect every 18 months, replace every 15 years

• DC bus >750 V or <450 V under load
• IGBT thermal sensor >85 °C with fan running
• Brake chopper faults ≥3 times in 30 days
• Capacitor bulge or ESR >150 % of spec
• “EF9 Drive Fault” persistent (internal IGBT desaturation)

6. Extending Life – 3 Pro Tips

1. Keep ambient <40 °C; every 10 °C rise halves capacitor life
2. Torque DC lugs annually; loose connections cause arcing and ozone
3. Run built-in capacitor test (P9.21) every 6 months; logs capacitance trend

7. Why Buy CPI32 from Nanjing Zhuye Elevator Parts?

• Factory-new, not refurbished; passes 4 h burn-in at 60 °C full load
• Built-in 3 % line reactor — no extra purchase
• Dual stock: 90 pcs Nanjing, 30 pcs Dubai — next-day air to 65 countries
• Bundle kit: inverter + 4 Ω brake resistor + 3 m shielded motor cable — 8 % discount
• 24 months warranty against IGBT failure or over-temperature
• 7×24 WhatsApp/WeChat video support; average response 12 min
