Elevator Fan RAH2260B1-C Brief Introduction

1. What RAH2260B1-C Really Is

• Size: 60 × 60 × 25 mm — fits inside any COP or side panel
• Voltage: 24 VDC ±10 %, 0.15 A, 3.6 W — saves battery energy
• Airflow: 22 L/min, 18 dB(A) at 1 m — quieter than a whisper
• Bearing: dual-ball, 50,000 h @ 40 °C, -25 °C to +80 °C
• Material: UL94 V-0 ABS, IP54, UV-stabilised for outdoor scenic lifts
• Connectors: 2-way Molex 250, locking, gold-plated
• Pack Unit: 1 fan + 2 screws + 1 × 2 mm Allen key + EVA vibration pad

2. Where It Is Used

• Otis Gen2-R2®, SkyRise®, Xizi super-MRL 1.0–4.0 m s⁻¹
• Thyssen TCM-MC3 retrofit kits with 24 VDC bus
• Chinese MRL controllers with 60 mm cut-out
• Suitable for COP, side panel or top-of-car mounting

3. Installation – 5-Minute Retrofit

1. Remove old fan — undo 2 M3 screws; unplug 2-way Molex.
2. Clean surface — IPA wipe to remove dust and oil; allow 30 s to dry.
3. Mount RAH2260B1-C — push into 60 mm cut-out until snap-ring clicks; stick EVA pad.
4. Connect plug — red +24 V, black 0 V, lock Molex until click.
5. Test — run car on inspection; fan must start within 3 s and stop 3 min after stop.

4. Daily Operation – What the Fan Actually Does

• Circulates 22 L/min — prevents condensation and CO₂ build-up
• Runs only when car moves — saves 0.15 A × 3 min = 0.0075 Ah per trip
• Ball-bearing design eliminates squeaks; <18 dB(A) at 1 m
• IP54 gasket resists brake-dust ingress; UV-stabilised for outdoor shafts
• Temperature range -25 °C to +80 °C — outdoor scenic lifts included

5. Replacement Cycle & Preventive Maintenance

• High-traffic office (>1,000 trips day⁻¹) – blow dust every 3 months, replace fan every 4 years
• Residential tower (300–600 trips day⁻¹) – inspect annually, replace every 6 years
• Low-rise freight (≤200 trips day⁻¹) – inspect every 18 months, replace every 8 years

• Airflow <18 L/min (anemometer test)
• Noise >25 dB(A) at 1 m during run
• Bearing temperature >65 °C after 10 min run
• Current >0.2 A or <0.1 A (multimeter test)
• UV discoloration >50 % surface area

6. Extending Life – 3 Pro Tips

1. Keep filter mesh clean; brake-dust blocks blades and increases noise
2. Never over-grease—ball-bearing is sealed for life; excess attracts grit
3. Store on lanyard; prevents loss and ground strikes during service

7. Why Buy RAH2260B1-C from Nanjing Zhuye Elevator Parts?

• Factory-new, not refurbished; passes 1,000-hour salt-spray and 50,000-cycle noise test
• Ball-bearing sealed for life — no re-greasing after 3 months
• Dual stock: 5,000 pcs Nanjing, 2,000 pcs Dubai — next-day to 65 countries
• Bundle kit: fan + 2 SS screws + EVA pad — 5 % cheaper than single OEM piece
• 24 months warranty against bearing failure or abnormal noise
• 7×24 WhatsApp/WeChat video support; average response 10 minutes
