Elevator Door Operator Motor PM5182027
|
Product Name |
Elevator Door Operator Motor |
| Model Number |
PM5182027 |
|
Quality
|
Original.Brand New
|
|
Payment
|
T/T. Paypal. Western Union
|
|
Delivery
|
3-5 Working Days
|
|
Packaging
|
Packed by carton
|
Elevator Door Operator Motor PM5182027: High-Efficiency PMSM Component from Nanjing Zhuye Elevatorparts
The Elevator Door Operator Motor PM5182027 is a high-performance permanent magnet synchronous motor (PMSM), serving as the core drive unit for modern elevator door systems. It delivers stable, precise power to control the smooth opening and closing of car and landing doors, with its compact structure and high efficiency making it a preferred choice for medium-load elevators. Exclusively supplied by Nanjing Zhuye Elevatorparts, this motor complies with international standards such as EN 81-1 and GB/T 18488-2015, featuring a rated torque of 2.5Nm, wide speed regulation range (150-1500r/min), and power density superior to traditional asynchronous motors. It is widely compatible with mainstream brands like Otis, Schindler, and domestic elevators such as Midea and Hitachi, applied in residential buildings, commercial complexes, and office towers.
Nanjing Zhuye Elevatorparts upholds strict quality control standards, and the PM5182027 motor is a prime example of this commitment. Each unit undergoes rigorous pre-delivery testing, including high-low temperature (-25℃ to 85℃) resistance tests, noise level detection (≤55dB), insulation resistance verification (≥2MΩ with 500V megohmmeter), and torque performance calibration. Adopting a neodymium-iron-boron permanent magnet core and high-purity copper windings, it achieves an efficiency of over 92% and eliminates the need for carbon brushes, reducing maintenance costs. The cast aluminum shell ensures excellent heat dissipation, while the sealed bearing with ZL-3 lithium-based grease supports long-term stable operation. Built-in overcurrent, overheating, and undervoltage protection functions prevent damage from abnormal working conditions.
Usage Guide for Elevator Door Operator Motor PM5182027
Proper installation, wiring, debugging, and maintenance are crucial to maximizing the service life and performance of the PM5182027 motor. Nanjing Zhuye Elevatorparts strongly recommends operations be performed by certified technicians. Before installation, confirm the motor model matches the door operator and control system. Refer to the product manual for wiring diagrams and parameter settings, or contact our technical support team for assistance. Note: Cut off the main power supply before operation, wear protective gear, and ensure a dry, dust-free installation environment.
1. Pre-Installation Preparation
First, cut off the elevator’s main power supply and lock the switch, then move the car to a middle floor to ensure safe operation space. Prepare professional tools: torque wrench, screwdrivers, 500V megohmmeter, level ruler, wire strippers, and insulation tape. Clean the door operator bracket to remove dust and oil stains. Inspect the motor for external damage (cracked shell, loose terminals) and test insulation resistance and winding continuity. Check matching components such as belts, pulleys, and encoders for wear, replacing damaged parts in advance.
2. Installation & Wiring
Fix the PM5182027 motor on the door operator bracket with high-strength bolts, using a level ruler to ensure horizontal installation (tolerance ±1mm). Tighten bolts to the specification (M8 thread: 8-10N·m) to prevent vibration-induced loosening. Follow the wiring diagram to connect three-phase power wires and encoder signal wires to the controller. Control wire stripping length to 6-8mm, ensure firm terminal connections, and separate power and signal wires to reduce interference. Install the protective cover after wiring, and adjust belt tension to 3-5mm deflection under 5N force for smooth power transmission.
3. Debugging & Daily Maintenance
After installation, restore power and debug. Set controller parameters (acceleration/deceleration time, rated speed) to match the motor, and run no-load tests first to check for abnormal noise or overheating. Conduct load tests to ensure doors open/close smoothly and position accurately. For daily maintenance, follow TSG T5002—2017 regulations: Clean the motor shell and cooling vents monthly; inspect bolts, wiring, and bearing temperature. Every 5000 hours, replace bearing lubricating grease and check insulation resistance. For harsh environments, double the inspection frequency and apply anti-rust agent to metal parts.
Replacement Cycle of Elevator Door Operator Motor PM5182027
The replacement cycle of the PM5182027 motor depends on usage frequency, environment, and maintenance quality. Under normal conditions—12-24 hours of daily operation with regular maintenance—Nanjing Zhuye Elevatorparts recommends a 6-8 year cycle. This is based on field data and industry standards, considering permanent magnet aging, bearing wear, and insulation degradation over long-term use.
For high-traffic areas (airports, subway stations) or harsh environments (high humidity, heavy dust), shorten the cycle to 4-6 years. High-frequency operation accelerates component wear, while harsh conditions cause corrosion and insulation damage. For low-usage elevators (villas, small offices), proper maintenance extends the cycle to 8-10 years. Motors over 7 years old require semi-annual professional inspections by Nanjing Zhuye Elevatorparts technicians.
Replace the motor immediately if: It produces abnormal noise/vibration or overheats frequently (surface temperature >85℃); insulation resistance drops below 0.5MΩ; speed regulation fails due to encoder malfunction; it causes frequent door system faults; the shell is severely corroded; it fails annual safety inspections. Always use genuine PM5182027 motors from Nanjing Zhuye Elevatorparts for compatibility and safety.
The PM5182027 motor from Nanjing Zhuye Elevatorparts combines high efficiency, compact design, and reliable performance, ideal for elevator door system upgrades and maintenance. Backed by strict quality control, advanced PMSM technology, and comprehensive after-sales service, it is trusted globally by maintenance firms and property managers. We provide 100% genuine motors, plus professional support including model matching, on-site debugging, and technical consultation. Choose Nanjing Zhuye Elevatorparts for premium elevator components and tailored solutions.
