Elevator Limit Switch IF17B-05-NO
Usage, Replacement Cycle & Maintenance Guide
By Nanjing Zhuye Elevatorparts

Introduction
The IF17B-05-NO precision limit switch is the silent sentinel that prevents over-travel in elevator systems. Designed and distributed worldwide by Nanjing Zhuye Elevatorparts, this snap-action switch meets EN 81-20/50 and ASME A17.1, delivering 1 million+ mechanical cycles with zero false tripping. The following 800-word English guide covers correct installation, daily operation, and the recommended replacement schedule to keep every lift within safe travel limits.

1. Product Highlights

• 1 NO contact, 15 A @ 250 V AC for direct safety-chain wiring
• IP65 ABS enclosure resists dust, oil and high humidity
• Pre-wired 3 m PUR cable with M12 connector – tool-free hook-up
• Roller lever 17 mm stroke for positive-break actuation
• Operating temperature –20 °C to +70 °C

1. Installation Method
   Step 1 – Preparation

• De-energise the lift; lock-out/tag-out main breaker and verify zero energy.
• Record switch serial number and mounting position in the maintenance log.
•

Step 2 – Mounting

• Position the switch on the hoistway bracket 5 mm before the final limit of car travel (per EN 81-20).
• Use supplied M5 × 30 mm stainless screws; torque to 8 N·m.
• Ensure roller lever is perpendicular to the cam plate (±2°).

Step 3 – Wiring

• Route 3-core 1.5 mm² cable through the PG7 gland.
• Connect brown (NO), blue (common), green/yellow (earth) to the safety-chain terminals.
• Secure strain relief to prevent cable fatigue.

Step 4 – Commissioning

• Restore power and cycle the car to the limit position; switch must open within 1 mm.
• LED on controller must change state; record trip distance and technician signature.

1. Daily & Preventive Maintenance
   Daily (Building Staff)

• Visual check—roller and lever must be free of debris.
• Ensure cable gland is tight and no cracks in housing.

Monthly

• Clean roller and cam with 70 % IPA; lubricate pivot sparingly with PTFE spray.

Quarterly

• Measure contact resistance (<0.1 Ω) and insulation (>10 MΩ @ 500 V).
• Cycle the switch 50 times under load to verify snap-action.
•

Annually

• Replace desiccant pack if present.
• Perform full safety-chain test including governor and door locks.

1. Replacement Cycle & Indicators
   Standard Duty: 5–7 years or 250,000 cycles
   High-Traffic: 3–4 years or 150,000 cycles
   Mandatory Replacement Signs

• Roller wear >1 mm or lever play >3°
• Contact welding or resistance >1 Ω
• Cracks, corrosion, or IP65 seal failure
• Frequent “limit fault” alarms in the controller

Keep one spare IF17B-05-NO per 15 elevators for <2-hour service turnaround.

5. Why Choose Nanjing Zhuye Elevatorparts?

• Full traceability—laser-etched serial and QR code on every switch.
• Ships same day to 60+ countries via DHL/FedEx Express.
• 24/7 multilingual hotline and on-site training.
• Competitive tiered pricing and custom cable lengths for OEM projects.
•

5. Conclusion
   The IF17B-05-NO limit switch is small but mission-critical. By following the installation, testing, and replacement guidelines—and sourcing only from Nanjing Zhuye Elevatorparts—facility managers and service teams can guarantee code compliance, reduce downtime, and protect every passenger who rides the lift.
